Creating Your Own Chess Game on iPad: A Prototype Guide

November 27, 2024
Creating Your Own Chess Game on iPad: A Prototype Guide

Creating your own chess game on iPad starts with a prototype you can test. In hyperPad, the useful first milestone is a local two-player board where each piece can be selected, valid destinations are shown, captures work, and the turn changes only after a legal move.

A finished chess implementation also needs check, checkmate, stalemate, castling, en passant, promotion, and draw rules. Build those after the basic board state is reliable. This keeps the project testable while you learn how a rule-based game works.

Start with a small chess prototype

Use one Scene for the board and UI. Begin with kings and rooks, then add one piece type at a time. Rooks are a practical first test because their movement exposes two important problems: a move must stay on one rank or file, and another piece can block the path.

Create an 8 × 8 board from square Objects. Give each square a coordinate such as a1 or store its file and rank as Object Attributes. Add separate Objects for the pieces. Keep the artwork simple until the rules work.

Object or valueState to storeWhy it matters
Board squarefile, rank, occupiedByIdentifies the destination and whether it is open
Chess piecepieceType, side, file, rank, hasMovedSupports movement rules, turns, and special moves
Game controllercurrentSide, selectedPiece, gameStateKeeps turn logic separate from the pieces

Use consistent values such as white and black for side, and playing, check, or finished for gameState. Consistent state is easier to inspect when a move fails.

Build the select, validate, move loop

A chess turn can be reduced to four stages: select a piece, choose a square, validate the move, then update the board.

1. Select the active side's piece

Add Started Touching to a piece. Use If to check that:

  • the game is still in the playing state;
  • the piece's side matches currentSide;
  • no other action is already being resolved.

When those checks pass, store the selected piece and give it a clear visual state. A highlight or outline is more useful than changing the piece's position before a destination has been approved.

2. Read the destination square

When the player touches a square, read its file and rank. Compare those values with the selected piece's current file and rank.

For a rook, a basic destination is valid only when the file stays the same or the rank stays the same. Then inspect each square between the start and destination. If any intervening square is occupied, reject the move. If the destination contains a piece from the same side, reject it as well.

Do not move the Object first and correct it afterward. Validate the state before changing the board.

3. Resolve a move or capture

After a valid move:

  1. Clear the starting square's occupiedBy value.
  2. If an opposing piece occupies the destination, use Destroy Object on that piece.
  3. Place the selected piece at the destination.
  4. Use Set Attribute to update the piece's file, rank, and hasMoved state.
  5. Set the destination square's occupiedBy value.
  6. Clear the selection highlight.

Keep these updates together. If the Object moves but the stored square state does not change, later rule checks will use the wrong board position.

4. Change turns last

Switch currentSide only after a legal move finishes. An invalid touch should leave the same player in control.

Update a UI label so both players can see whose turn it is. This is a small detail, but it makes turn-state bugs much easier to catch during playtesting.

Add each chess piece as a separate rule

Keep each movement rule in its own Behavior branch. Create and test one rule at a time.

PieceMovement checkExtra state or validation
RookSame file or same rankEvery square in the path must be clear
BishopFile change equals rank changeEvery diagonal square in the path must be clear
QueenValid rook or bishop movementPath must be clear
KnightTwo squares on one axis and one on the otherCan jump over occupied squares
KingOne square in any directionDestination cannot leave the king in check
PawnMoves forward; captures diagonallyDirection, first move, en passant, and promotion need separate checks

The king rule changes the architecture. A move is not legal if it leaves that player's king under attack. One reliable approach is to evaluate a proposed board state, test whether any opposing piece attacks the king's square, and commit the move only when the king remains safe.

Treat special rules as later milestones

Once ordinary movement and captures are stable, add the remaining chess rules deliberately:

  • Castling: neither the king nor rook has moved, the path is clear, and the king does not move through check.
  • En passant: the eligible capture exists for one reply immediately after a pawn advances two squares.
  • Promotion: a pawn reaching the final rank must be replaced by the player's selected piece type.
  • Checkmate and stalemate: evaluate whether the active side has any legal move, then distinguish whether its king is under attack.
  • Draws: decide how you will handle repetition, insufficient material, and move-count rules.

A computer opponent is a separate system that needs its own design. Complete and test the local two-player rules before planning move search or difficulty levels.

Test the rules as well as the animations

For every piece, test a valid move, an invalid pattern, a blocked path, a friendly occupied destination, and an opposing occupied destination. Also test what happens when a move would expose the player's own king.

Record failures by rule and board state. A piece arriving at the right square does not prove the stored state, capture logic, or next turn is correct.

If you need the broader structure for boards, turns, and win conditions, use the digital board game guide. For a deeper look at alternating player state, read how to make a digital play-by-mail game on iPad.

Build the smallest complete turn

Start with two kings and two rooks. Make selection, path validation, capture, turn switching, and reset work from the same starting position every time. Once that loop is dependable, add the next piece rule without changing the working ones.
